A no-handle auxiliary lock that mounts where a mortise body cannot go: steel gates, storage rooms, utility cabinets. Widest operating range in the range, because there is no screen and no lithium cell in the sun.
Specification
| Parameter | Value |
|---|---|
| Unlock methods | Fingerprint, PIN, one-time PIN, key |
| Capacity | 50 fingerprints, 100 PINs |
| Dimensions | Front 137 × 73 × 91 mm / rear 149 × 73 × 49 mm |
| Cylinder body | 111 × 53 × 25 mm |
| Battery | 4 × AA, DC 6 V |
| Operating temp. | −25 °C to +85 °C |
| Weight | 0.7 kg |
Documents
The datasheet, type-test report for GA374-2019 and GB21556-2008, and the packing list ship with every order. Request the pack on the contact page.
